Host Bus Interface |
8-Lane PCI Express(R) 3.0 |
Ports |
8 x external |
Drive Connectors |
2 x SFF-8644 |
Data Transfer Rate |
Up to 12Gb/s per port |
Drive Support |
Up to 8 x SAS/SATA HDDs/SSD |
Cache Memory |
1GB on-board DDR3-1600 SDRAM with ECC protection |
Physical Dimensions |
Low Profile 169.5(L) x 64.4(H) mm |
BBM Support |
ARC-1883-CAP / ARC-6120BA-T121-12G |
Power Dissipation |
Typical 14.4W |
Operating Temperature |
0 °C to 60 °C with 200 LFM airflow |
Operating Humidity |
10% to 85%, non-condensing |
RAID Levels |
RAID level 0, 1, 10(1E), 3, 5, 6, 30, 50, 60, Single Disk or JBOD |
RAID-on-Chip Controller |
Dual Core RAID-on-Chip 1.2GHz |
RAID Features |
Multiple RAID 0 and RAID 10 (1E) support (RAID 00 and RAID100) |
|
Support RAID 1 - Multi Mirroring and Mirrored Pass-Through Disk |
|
Multiple RAID selection |
|
Configurable stripe size up to 1MB |
|
Support HDD firmware update |
|
Online array roaming |
|
Online RAID level/stripe size migration |
|
Online capacity expansion and RAID level migration simultaneously |
|
Online volume set growth |
|
SED (self-encrypting drives) function support |
|
Multiple pairs SSD/HDD disk clone function |
|
SSD automatic monitor clone (AMC) support |
|
Instant availability and background initialization |
|
Support global and dedicated hot spare |
|
Automatic drive insertion/removal detection and rebuilding |
|
Support for native 4K and 512 byte sector SAS and SATA devices |
|
Support intelligent power management to save energy and extend service life |
|
Support NTP protocol synchronize RAID controller clock over the on board Ethernet port |
