Graphics Engine |
AMD Radeon RX 7600 XT |
Bus Standard |
PCI Express 4.0 x8 |
DirectX |
12 Ultimate |
OpenGL |
4.6 |
Memory |
16GB GDDR6 |
Engine Clock |
Boost Clock* Up to 2810 MHz |
|
Game Clock** 2539 MHz |
|
*Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to; thermal conditions and variation in applications and workloads. |
|
**Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. |
Stream Processors |
2048 |
Memory Clock |
18 Gbps |
Memory Interface |
128-bit |
Resolution |
Digital Max Resolution 7680 x 4320 |
Interface |
3 x DisplayPort 2.1* |
|
1 x HDMI 2.1 |
|
*DisplayPort (DP) 2.1 on any one or two ports. DisplayPort (DP) 1.4a on any and up to 3 ports simultaneously. |
HDCP |
Yes |
Multi-view |
4 |
Recommended PSU |
650W |
Power Connector |
2 x 8-pin |
Accessories |
1 x Quick Installation Guide |
Dimensions |
304 x 131 x 51 mm, 2.6-slot |
Net Weight |
945 g |
