商品スペック
Platform | Dimensions 3.3-in x 4.1-in |
---|---|
Chipset | Intel JHL8540 Thunderbolt 4 Controller |
External Connectors | 2 x Thunderbolt 4 Type-C Ports (with up to 40Gbps bandwidth)* |
1 x TBT Header | |
2 x DisplayPort IN PortsM | |
1 x USB 2.0 Header | |
*Supports daisy-chaining of up to six Thunderbolt devices | |
Supports USB PD 3.0 up to 9V@3A (27W) / 5V@3A (15W) charging | |
Interface | PCI Express 3.0 x4 interface |
Graphics | Supports ThunderboltTM 4 interface with max. resolution of 5K (5120 x 2880)@ 60Hz for one display over a single cable connection |
Supports ThunderboltTM 4 interface with max. resolution of 4K x 2K (4096x2160)@ 60Hz for dual displays over a single cable connection | |
Supports up to two streams (eight lanes) of DisplayPort video bandwidth ; supports daisy-chaining of multiple DisplayPort monitors | |
Data Rate | Supports 40Gbps bi-directional bandwidth per channel with Thunderbolt 4 port |
OS | Microsoft Windows 10 64-bit / 11 64-bit |
Accessories | Quick Installation Guide, Support CD |
1 x TBT Header Cable | |
2 x DisplayPort Cables | |
1 x USB 2.0 Cable |
