RAID-on-Chip Controller |
ARM_based storage I/O processor(R) 1.066 GHz |
Cache Memory |
512 MB on-board DDR3-1066 SDRAM with ECC protection |
Host Bus Interface |
4-Lane PCI Express(R) 2.0 |
Ports |
8 x internal |
Drive Connectors |
2 x SFF-8087 |
Data Transfer Rate |
Up to 6Gb/s per port |
Drive Support |
Up to 8 x SATA HDDs/SSD |
Physical Dimensions |
Low Profile 168(L) x 64.4(H) mm |
Power Dissipation |
Typical 11W |
Operating Temperature |
0 °C to 60 °C with 200 LFM airflow |
Operating Humidity |
10% to 85%, non-condensing |
BBM Support |
ARC-6120BA-T121-12G |
RAID Levels |
RAID level 0, 1, 10(1E), 3, 5, 6, 30, 50, 60 and Single Disk |
RAID Features |
Multiple RAID selection |
|
Configurable stripe size up to 1MB |
|
Support HDD firmware update |
|
Online array roaming |
|
Online RAID level/stripe size migration |
|
Online capacity expansion and RAID level migration simultaneously |
|
Online volume set growth |
|
SED (self-encrypting drives) function support |
|
Multiple pairs SSD/HDD disk clone function |
|
SSD automatic monitor clone (AMC) support |
|
Instant availability and background initialization |
|
Support global and dedicated hot spare |
|
Automatic drive insertion/removal detection and rebuilding |
|
Support for native 4K and 512 byte sector SAS and SATA devices |
|
Support intelligent power management to save energy and extend service life |
|
Support NTP protocol synchronize RAID controller clock over the on board Ethernet port |
