商品スペック
Onboard RAID Processor | RAID-On-Chip onboard |
---|---|
Onboard Cache | 512MB DDR 3 Cache memory with ECC protection |
Optional BBU Module | Yes |
Port Type | RocketRAID 4520SGL - 2x SFF-8087 (Mini-SAS) |
RocketRAID 4522SGL - 2x SFF-8088 (Mini-SAS) | |
Number of Channel / Port | 8x 6Gb/s SAS/SATA Channels |
Number of Devices | 8x SAS/SATA Hard Drive/SSD |
<Note> Desktop HDD's are not supported. | |
Bus Interface | PCIe 2.0 x8 |
Form Factor | Low Profile |
Dimensions | 6.575"( L ) x 2.667"( H ) |
Weight | RocketRAID 4520SGL - 0.25lbs. |
RocketRAID 4522SGL - 0.28lbs. | |
RAID Mode | 0, 1, 5, 6, 10, 50 and JBOD / Non-RAID Mode |
<Note> Bootable RAID 6 is not supported | |
Operating System | Windows 7 and later |
Windows Server 2008 and later | |
Linux RedHat Enterprise, Open SuSE, Fedora Core, Debian, Ubuntu | |
Linux Driver embedded into Kernel 3.9.4 and later | |
macOS 10.6 and later | |
Driver embedded into macOS 10.9 and later |
